Android Tutorial: Model-View-ViewModel Awkwardness

8 min readApr 6, 2019

The purpose of this article is not to claim that MVVM is a bad architecture. Rather, I wish to highlight some of the reasons why I think it leads to confusion among many developers, along with some practical information on how to deal with the awkward separation of concerns that this pattern can present.

This article is accompanied by a video tutorial covering many of the same ideas here.

It is quite likely that the most common question I am asked during my live Q&As, is something like:

MVVM vs MVP/MVC?

Whenever I am asked this question, I am quick emphasize the idea that no single GUI architecture works great in all situations. Why, you may ask? The best architecture (or at least a good choice) for a given application depends strongly on the requirements at hand. Let us briefly think about what this word requirements actually means:

How complex is your UI? A simple UI does not generally require complex logic to coordinate it; whereas a complex UI may require extensive logic and fine-grained control to work smoothly.
How much do you care about testing? Generally speaking, classes which are tightly coupled to frameworks and the OS (especially the user interface) require extra work to test.
How much re-usability and abstraction do you wish to promote? What if you want to share the back end, domain, and even presentation logic of your application across different platforms?
Are you by nature pragmatic, perfectionist, lazy, or all of the above at different times, in different situations?

I would love to write an article where I discuss in fine detail how MVVM works with respect to the requirements and concerns listed above. Unfortunately, some of you have likely been mislead (as I was several years ago when I first looked in to the pattern), in to thinking that there is one way to do MVVM. Instead, I will discuss two different approaches to the general idea of MVVM which present very distinct benefits and disadvantages. But first, let us start with the general idea.

THOU SHALT NOT REFERENCE THY VIEW CLASSES

For my ESL friends who cannot read old English: “YOU MAY NOT REFERENCE VIEW CLASSES”

Apart from using the name ViewModel (which itself can be quite confusing depending on how you use it), the one iron-clad rule of MVVM architecture which I have not seen disputed, is that you may never reference a View, from ViewModel. Now, the first area of confusion can arise from this word “reference,” which I will restate using several different levels of jargon:

Your ViewModels may not possess any references (member variables, properties, mutable/immutable fields) to any Views
Your ViewModels may not depend on any Views
Your ViewModels may not talk directly to your Views

Now, on the Android platform, the reason for this rule is not simply that breaking it is bad because someone who seems to know about software architecture told you it is bad. When using the ViewModel class from Architecture Components (which is designed to have its instance persist longer than the Fragment/Activity lifecycle when appropriate), referencing a View is asking for SERIOUS MEMORY LEAKS.

As for why MVVM in general does not allow such references, the goal is hypothetically to make both the View and the ViewModel easier to test and write. Others may also point out that it promotes reusability of ViewModels, but this is exactly where things break down with this pattern.

ViewLogic + ViewModel or View + ViewModelController?

When I said “break down” in the previous section, I do not mean to say that the pattern literally breaks. I mean that it breaks down into (at least) two different approaches which have very distinct appearances, benefits, and consequences. Let us consider these two approaches, and when you may wish to prefer one over the other.

First Approach: Prioritize Reusable ViewModels

As far as I can tell (we are getting in to murky water), most people who implement MVVM make it a goal to promote re-usability of ViewModels, so that they may be reused for n number of different Views (many-to-one ratio). In simple terms, there are two ways in which this re-usability is achieved:

By not referencing a specific View. Hopefully this is not news to you at this point.
By knowing as little as possible about the details of the UI in general

The second point may sound vague or counter-intuitive (how can it know anything about something which it does not reference?), so I think it is time to look at some code:

class NoteViewModel(val repo: NoteRepo): ViewModel(){
    //Note: you may also publish data to the View via Databinding, RxJava Observables, and other approaches. Although I do not like to use LiveData in back end classes, it works great with Android front end with AAC    val noteState: MutableLiveData<Note>()
    //...    fun handleEvent(event: NoteEvent) {
        when (event) {
            is NoteEvent.OnStart -> getNote(event.noteId)
            //...
        }
    }    private fun getNote(noteId: String){
        noteState.value = repo.getNote(noteId)
    }
}

While this is a very simplified example, the point is that the only thing which this particular ViewModel exposes publicly (other than the handleEvent function), is a simple Note object:

data class Note(val creationDate:String,
                val contents:String,
                val imageUrl: String,
                val creator: User?)

Now, with this particular approach, the ViewModel is well and truly decoupled from not just a particular View, but also the details, and by extension, presentation logic of any particular View. If what I am saying still seems vague, I promise it will be clear once I describe the other approach.

Although my earlier heading, “ViewLogic + ViewModel…” is not meant to be used or taken serious; I am pointing out the fact that by having very decoupled and re-usable ViewModels, we are now depending on the View itself to do the work of figuring out how exactly to render/bind this Note object on screen. Some of us do not like filling View classes with Logic.

Now, this is where things get very muddy and dependent on project requirements. I am not saying that filling View classes with logic such as…:

private fun observeViewModel() {
    viewModel.notes.observe(
        viewLifecycleOwner,
        Observer { notes: List<Note> ->
            if (notes.isEmpty()) showEmptyState()
            else showNoteList(notes)
        }
    )
   //..
}

…is always a bad thing (after all, rarely is the logic complex), but at best it cries out for testing (testing something tightly coupled to the OS); at worst, it is a failure to apply what I consider to be the golden principle of any good architecture: Separation of concerns.

My personal opinion is that it is worth it to apply separation of concerns to a very high degree; but make no mistake that plenty of cash cow applications have been written by people who do not have the faintest clue about what that means. In any case, the approach we will discuss next, while having its own side effects, once again removes the presentation logic from the View; well, most of it anyways.

Second Approach: Humble View, Control-Freak ViewModel

Sometimes not having fine-grained control over your Views (which is a consequence of prioritizing re-usability of ViewModels), actually kind of sucks. To make me even less enthusiastic about applying the previous approach to my day to day Android work, I find that I often do not need to reuse a ViewModel.

Ironically, “too much abstraction” is a common critique of MVP over MVVM.

With that being said, one cannot simply add a reference back in to the ViewModel in order to regain this fine-grained control over the View. That would basically just be MVP + memory leaks (assuming you are still using ViewModel from AAC).

The alternative then, is to build your ViewModels such that they contain almost all of the behaviour, state, and presentation logic of a given View. The View must still bind to the ViewModel of course, but enough details about the View are present in the ViewModel that the View’s functions are reduced to one liners (with small exceptions). In Martin Fowler’s naming conventions, this is known as Passive View/Screen. A more generally applicable name for this approach is the Humble Object Pattern.

In order to achieve this, you must essentially have your ViewModel possess an observable field (however you achieve that; data binding, Rx, LiveData, whatever) for every control or widget present in the View:

class UserViewModel(
    val repo: IUserRepository,
){

    //The actual data model is kept private to avoid unwanted tampering
    private val userState = MutableLiveData<User>()

    //Control Logic
    internal val authAttemptState = MutableLiveData<Unit>()
    internal val startAnimation = MutableLiveData<Unit>()

    //UI Binding
    internal val signInStatusText = MutableLiveData<String>()
    internal val authButtonText = MutableLiveData<String>()
    internal val satelliteDrawable = MutableLiveData<String>()

    private fun showErrorState() {
        signInStatusText.value = LOGIN_ERROR
        authButtonText.value = SIGN_IN
        satelliteDrawable.value = ANTENNA_EMPTY
    }
    //...
}

Subsequently, the View will still need to wire itself up to the ViewModel, but the functions required to do so become trivially simple to write:

class LoginView : Fragment() {

    private lateinit var viewModel: UserViewModel
    //...

    //Create and bind to ViewModel
    override fun onStart() {
        super.onStart()
        viewModel = ViewModelProviders.of(
        //...
        ).get(UserViewModel::class.java)

        //start background anim
        (root_fragment_login.background as AnimationDrawable).startWithFade()

        setUpClickListeners()
        observeViewModel()

        viewModel.handleEvent(LoginEvent.OnStart)
    }

    private fun setUpClickListeners() {
      //...
    }

    private fun observeViewModel() {
        viewModel.signInStatusText.observe(
            viewLifecycleOwner,
            Observer {
                //"it" is the value of the MutableLiveData object, which is inferred to be a String automatically
                lbl_login_status_display.text = it
            }
        )

        viewModel.authButtonText.observe(
            viewLifecycleOwner,
            Observer {
                btn_auth_attempt.text = it
            }
        )

        viewModel.startAnimation.observe(
            viewLifecycleOwner,
            Observer {
                imv_antenna_animation.setImageResource(
                    resources.getIdentifier(ANTENNA_LOOP, "drawable", activity?.packageName)
                )
                (imv_antenna_animation.drawable as AnimationDrawable).start()
            }
        )

        viewModel.authAttemptState.observe(
            viewLifecycleOwner,
            Observer { startSignInFlow() }
        )

        viewModel.satelliteDrawable.observe(
            viewLifecycleOwner,
            Observer {
                imv_antenna_animation.setImageResource(
                    resources.getIdentifier(it, "drawable", activity?.packageName)
                )
            }
        )
    }

You can find the full code for this example here. Leave us a Star, would you?

As you have probably noticed, we are probably not going to be re-using this ViewModel anywhere else. Also, our View has become sufficiently humble (depending on your standards and preferences for code coverage), and very easy to write.

Sometimes you will run in to situations where you must find some kind of half-measure between the distribution of presentation logic between Views and ViewModels, which does not strictly follow either of these approaches. I am not advocating one approach over another, but rather encouraging you to be flexible in your approach, based on the requirements at hand.

Preferences And Requirements

The point of this article was to look at two different approaches which a developer can take in terms of constructing a MVVM style GUI architecture on the Android Platform (with some carry over to other platforms).

In truth, we could get more specific about minute differences even within these two approaches.

Should the View observe a field for every individual widget/control it posesses, or should it observe one field which publishes a single model to render the entire View anew each time?
Maybe we could avoid having to make our ViewModels one-to-one, while keeping our Views as Humble Objects, simply by adding something like a Presenter or Controller to the mix?

Talk is cheap, and I strongly advise you to try and learn these things in the code so that you do not need to rely on people like me to tell you what to do. Ultimately, I think the two elements which make for a great architecture come down to the following considerations:

Play with several approaches until you find one which you prefer. This is best done by actually building an application (it can be simple) in each style, and seeing what feels right.
Understand that preferences aside, different styles will tend to emphasize different benefits in exchange for different deficits. Eventually, you will be able to pick good choices based on your understanding of the project requirements rather than blind faith.
